150L THC Remediation System
Processing Vessel
- Volume: 170L vessel holds up to 150 l of extract
- Pressure: Not pressurized
- Temperature: Max 125°C/257°F
- Material: 304 stainless steel
- Vessel: interior is polished to food grade level
- Tempriture measurement: Pt100 sensors
- Water Jacket volume: 95 Liters (25 gallons)
Condenser Vessel
- Volume: 16 Liter
- Pressure: Not pressurized
- Temperature: max 35°C (95°F)
- Material: 304 stainless steel
- Cleaning: Manual
- Flow path: Manual
Air Flow Control
- Air compressor: Compressed air
- Temperature range: 20°C to 50°C (68°F to 158°F)
Physical Dimensions
- Height: 2800 mm
- Length: 1500 mm
- Width: 1050 mm
- Total weight: apr. 400 kg
- Floor mounting area: min. 5 m²
- Ceiling height: 3 m
Control System
- Functions: Fully automatic programmable Logic Controller (PLC) touch screen interface with first level safety functionality.
- Safety: Automatic shutdown system to prevent the incident.
Software Controls
- Fully automatic
- 3 build in modes of operation
- Consistent results
